Airflow

王江南2025年9月5日大约 3 分钟

重载

airflow dags reserialize

默认密码启动会输出

airflow users reset-password --username admin --password 新密码

安装

services:
  airflow:
    build:
      context: .
      dockerfile: Dockerfile
      tags:
        - "registry.cn-hangzhou.aliyuncs.com/wjn0918/soft:airflow-latest"
    image: airflow
    container_name: airflow-standalone
    environment:
      - AIRFLOW__CORE__LOAD_EXAMPLES=False  # 不加载默认案例
    volumes:
      - ./dags:/root/airflow/dags
      - airflow-data:/root/airflow
    ports:
      - 8082:8080

volumes:
  airflow-data:

test

python xx.py

案例

from airflow.sdk import Variable,dag, task
import pendulum
from airflow.operators.python import get_current_context




@dag(
    schedule=None,
    start_date=pendulum.datetime(2021, 1, 1, tz="UTC"),
    catchup=False, # 是否开启回填
    tags=["example"],
)
def hello_variable():
    """
    hello variable
    """

    @task
    def get_variable():
        """
        get variable
        """
        appid = Variable.get("appid")
        print(f"the variable appid is {appid}")

    @task
    def get_currnet_time():
        """
        获取任务运行时间
        """
        context = get_current_context()
        execution_date = context['ds']
        print(f"Execution date is: {execution_date}")
    t1 = get_variable()
    t2 = get_currnet_time()
    t1 >> t2
hello_variable()

引用自身模块

注意

需要添加到 dag 开头

import sys
import os

# Dynamically add the dags folder to Python path
sys.path.append(os.path.dirname(os.path.abspath(__file__)))

from airflow.sdk import Variable,dag, task
import pendulum
import sys
import os

# Dynamically add the dags folder to Python path
sys.path.append(os.path.dirname(os.path.abspath(__file__)))


from utils.my_util import hello_util


@dag(
    schedule=None,
    start_date=pendulum.datetime(2021, 1, 1, tz="UTC"),
    catchup=False, # 是否开启回填
    tags=["example"],
)
def demo():
    """
    hello utils
    """

    @task
    def get_function():
        """
        get function from third py
        """
        hello_util()

    get_function()
demo()

配置

## 不加载案例
[core]
load_examples = False

重置数据库

airflow db reset

┌───────────── 分钟 (0 - 59)
│ ┌───────────── 小时 (0 - 23)
│ │ ┌───────────── 日 (1 - 31)
│ │ │ ┌───────────── 月 (1 - 12)
│ │ │ │ ┌───────────── 星期几 (0 - 7)（0 和 7 都代表星期日）
│ │ │ │ │
│ │ │ │ │
*/5 * * * * your-command

变量

配置

更改端口

base_url
port
internal_api_url
都需要修改

时区问题

@dag(
schedule="*/10 * * * *",
start_date=pendulum.datetime(2025, 7, 15, 17, 30, tz="Asia/Shanghai"), # 明确使用上海时区
catchup=True,
tags=["cl"],
)

补数据

catchup = True

airflow 会自动从开始时间补数据，所以设置为ture后需要调整start_date，不然会从开始时间一直补到现在

pkill -f "airflow"

分组中存在SQLExecuteQueryOperator 需要放到task后

import pendulum
import subprocess
import re

import pytz
from airflow.api_fastapi.execution_api.datamodels.taskinstance import DagRun
from airflow.executors.workloads import TaskInstance
from airflow.providers.common.sql.operators.sql import SQLExecuteQueryOperator
from airflow.sdk import dag, task, task_group
from airflow.providers.standard.operators.empty import EmptyOperator


@dag(
    schedule="*/5 * * * *",
    start_date=pendulum.datetime(2025, 7, 15, 17, tz="Asia/Shanghai"),
    catchup=False,
    tags=["sjzx"],
)
def sjzx_xmjcjl():
    """
    数据中心 校门进出记录
    """

    @task
    def extract_data(ti: TaskInstance = None, dag_run: DagRun = None):
        """运行 DataX 并提取记录数"""
        d = dag_run.data_interval_start
        shanghai_tz = pytz.timezone('Asia/Shanghai')
        d_shanghai = d.astimezone(shanghai_tz)
        bizdate = d_shanghai.strftime("%Y-%m-%d")

        print(f"DAG Run queued at: {d}")
        cmd = f"python /data/soft/datax_cs/bin/datax.py /data/soft/airflow/datax/ods_sr_sjzx_xmjcjl.json -p '-Dbizdate={bizdate} -Dhh={d_shanghai.hour:02d}'"
        print(f"执行： {cmd}")
        result = subprocess.run(cmd, shell=True, capture_output=True, text=True)

        log_output = result.stdout + result.stderr
        match = re.search(r"读出记录总数\s*:\s*(\d+)", log_output)
        record_count = int(match.group(1)) if match else 0
        print(f"[DataX] 读出记录总数: {record_count}")
        print(log_output)

        ti.xcom_push(key='record_count', value=record_count)
        ti.xcom_push(key='bizdate', value=bizdate)
        ti.xcom_push(key='hh', value=f"{d_shanghai.hour:02d}")

    @task.branch
    def branch_func(ti=None):
        record_count = int(ti.xcom_pull(key='record_count', task_ids='extract_data'))
        if record_count > 0:
            return "export_task"
        else:
            return "skip_task"

    @task_group(group_id="export_task")
    def export_task():

        @task.bash(cwd="/data/soft/airflow/etl")
        def export_access_person_record(ti=None):
            """门禁 进出记录"""
            bizdate = str(ti.xcom_pull(key='bizdate', task_ids='extract_data'))
            hh = str(ti.xcom_pull(key='hh', task_ids='extract_data'))
            return f"uv run access_person_record.py config_sr_pro.yaml {bizdate} {hh}"

        @task.bash(cwd="/data/soft/airflow/etl")
        def export_visitor_access_record(ti=None):
            """访客 进出记录"""
            bizdate = str(ti.xcom_pull(key='bizdate', task_ids='extract_data'))
            hh = str(ti.xcom_pull(key='hh', task_ids='extract_data'))
            return f"uv run visitor_access_record.py config_sr_pro.yaml {bizdate} {hh}"

        update_sx_fkzt = SQLExecuteQueryOperator(
            task_id="update_sx_fkzt",
            conn_id="sr_ywxt",
            sql="""
with t as (
-- 门禁当天人员进出记录
select
	job_no,
	access_type,
	access_time,
	row_number() over(partition by job_no order by access_time desc) as n
from t_access_person_record where workspace_id = 'SXXQ' and to_char(access_time, 'yyyy-MM-dd') = '${bizdate}' and name is not null
)
update ads_t_dp_ryzt
set
	sfzx = case when access_type = '1' then 1 else 0 end
	,jxsj = case when access_type = '1' then cast(access_time as varchar) else jxsj end
	,lxsj = case when access_type != '1' then cast(access_time as varchar) else lxsj end
from (
	select * from t where n = 1
) as t1
where ads_t_dp_ryzt.xh = t1.job_no
and workspace_id = 'SXXQ'
                          """
        )

        update_hz_fkzt = SQLExecuteQueryOperator(
            task_id="update_hz_fkzt",
            conn_id="sr_ywxt",
            sql="""
                            with t as (
                        -- 门禁当天人员进出记录
                        select
                          job_no,
                          access_type,
                          access_time,
                          row_number() over(partition by job_no order by access_time desc) as n
                        from t_access_person_record where workspace_id = 'HZXQ' and to_char(access_time, 'yyyy-MM-dd') = '${bizdate}' and name is not null
                        )
                        update ads_t_dp_ryzt
                        set
                          sfzx = case when access_type = '1' then 1 else 0 end
                          ,jxsj = case when access_type = '1' then cast(access_time as varchar) else jxsj end
                          ,lxsj = case when access_type != '1' then cast(access_time as varchar) else lxsj end
                        from (
                          select * from t where n = 1
                        ) as t1
                        where ads_t_dp_ryzt.xh = t1.job_no
                        and workspace_id = 'HZXQ'
                          """,
        )
        export_access_person_record() >> export_visitor_access_record() >> update_hz_fkzt >> update_sx_fkzt


    skip_task = EmptyOperator(task_id="skip_task")

    extract_data() >> branch_func() >> [export_task(), skip_task]


sjzx_xmjcjl()

自启

/etc/systemd/system/airflow.service


[Unit]
Description=Airflow Standalone
After=network.target

[Service]
User=root
Environment="PATH=/root/miniconda3/bin:/usr/local/sbin:/usr/local/bin:/usr/sbin:/usr/bin:/sbin:/bin"
ExecStart=/root/miniconda3/bin/airflow standalone
Restart=always
StandardOutput=journal
StandardError=journal

[Install]
WantedBy=multi-user.target
